Model

TXLP/2R

Quality Certificate

CE, ROHS, UL, TUV, GOST , ISO9001:2008

Brand Name

ANBANG

Twins conductor: multi-wire Nickel-Copper Alloy Heating Core provides excellent physsical flexibility and stability.
Silicon Rubber Insulation: -60°C~205°C.

PVC Outer Jacket:-25°C~105°C .
Double Protection: Aluminium Foil plus Braided Cooper Mesh to eliminate electromagnetic radiation, connected to the earth in case of any electro leakage.

Joint: The connecting part between the heating cable and the power line. To produce multi-protected joint, we adopt double shooting technique to ensure its good physical properties with outstanding water proof virtue.

Each cable completed with a 2m cold leading wire(not heating when electrically connected) at one end.
Voltage: 110V, 120V, 220V, 230V.

Anbang can customize from 10-30w/m as per your requirements under the Votage 120v,220v,230v

Specifications

Total Power

(watt)

Length

（m）

Resistance/230V

(Ω)

Voltage

(v)

TXLP/2R/17-18M

300

18

176.33

230

TXLP/2R/17-24M

400

24

132.25

230

TXLP/2R/17-29M

500

29

105.80

230

TXLP/2R/17-35M

600

35

88.17

230

TXLP/2R/17-41M

700

41

75.57

230

TXLP/2R/17-49M

840

49

62.98

230

TXLP/2R/17-59M

1000

59

52.9

230

TXLP/2R/17-74M

1250

74

42.32

230

TXLP/2R/17-81M

1370

81

38.61

230

TXLP/2R/17-100M

1700

100

31.12

230

TXLP/2R/17-118M

2050

118

25.80

230

TXLP/2R/17-129M

2200

129

24.41

230

TXLP/2R/17-141M

2400

141

22.04

230

TXLP/2R/17-153M

2600

153

20.35

230

TXLP/2R/17-165M

2800

165

18.89

230

TXLP/2R/17-176M

3000

176

17.63

230

TXLP/2R/17-194M

3300

194

16.03

230
