Underfloor heating cable single conductor 18.5w/m orange

HOME   PRODUCTS   Heating Cable







Underfloor heating cable (single conductor, 18.5w/m)


Model

TXLP/1

Quality Certificate

CE, ROHS, UL, TUV, GOST , ISO9001:2008

Brand Name

ANBANG



Specifications:


Single conductor: multi-wire Nickel-Copper Alloy Heating Core provides excellent physical flexibility and stability.
Silicon Rubber Insulation: -60°C~205°C.

PVC Outer Jacket:-25°C~105°C .
Double Protection: Aluminium Foil plus Braided Cooper Mesh to eliminate electromagnetic radiation, connected to the earth in case of any electro leakage.

Joint: The connecting part between the heating cable and the power line. To produce multi-protected joint, we adopt double shooting technique to ensure its good physical properties with outstanding water proof virtue.

Each cable completed with a 2m cold leading wire(not heating when electrically connected) at each end.
Voltage: 110V, 120V, 220V, 230V.

Anbang can customize from 10-30w/m as per your requirements under the Votage 120v,220v,230v



Specification

Total Power

(watt)

Length

（m）

Resistance

(Ω)

Voltage

(v)

TXLP/1/18.5-16M

300

16

176.33

230

TXLP/1/18.5-22M

400

22

132.25

230

TXLP/1/18.5-27M

500

27

105.80

230

TXLP/1/18.5-32M

600

32

88.17

230

TXLP/1/18.5-38M

700

38

75.57

230

TXLP/1/18.5-46M

850

46

62.24

230

TXLP/1/18.5-54M

1000

54

52.90

230

TXLP/1/18.5-65M

1200

65

44.08

230

TXLP/1/18.5-76M

1400

76

37.79

230

TXLP/1/18.5-86M

1600

86

33.06

230

TXLP/1/18.5-95M

1760

95

30.06

230

TXLP/1/18.5-108M

2000

108

26.45

230

TXLP/1/18.5-119M

2200

119

20.05

230

TXLP/1/18.5-130M

2400

130

22.04

230

TXLP/1/18.5-141M

2600

141

20.35

230

TXLP/1/18.5-151M

2800

151

18.89

230

TXLP/1/18.5-162M

3000

162

17.63

230

TXLP/1/18.5-170M

3150

170

16.80

230



Order Details:

MOQ

5000 meters.

Payment Terms

T/T: 30% in advance, 70% paid against the B/L copy

L/C at sight.

Remarks

1. OEM service available.

2. Sample order/trial order to be accepted.
3. Customized color box, cartons, shipping marks, and labels are available.

4. Installing instructions included.

5. Reparing kits(for installation) available upon request.

Packing

Customized.
